Truck 5

This specialized truck features a robust 15-ton (15T) AN-Prill body and is managed by a proportional CAN electrically controlled hydraulic system, capable of delivering blended product at a maximum rate of 1,000 lbs/min. It incorporates significant storage capacity, including a 1,000-gallon emulsion tank and a 270-gallon rear-mounted fuel oil tank. Operational efficiency is ensured by an 18-foot-long overhead auger for ANFO/Emulsion delivery, pneumatic bin vibrators to loosen any clumped product, and a 3-system hydraulic gate valve to safely isolate the auger from the Prill bin.

Furthermore, the truck is equipped with the V.E.S.C.O. dewatering system designed to remove standing water from blast holes. For operator safety, a single-side hydraulically controlled guard rail is integrated.a single-side, hydraulically controlled guard rail.

Features Include:

  • 1,000 Gallon Emulsion Tank
  • 15T Prill bin
  • 270-gallon fuel oil tank
  • Bin vibrator
  • Gate Valve
  • E.S.C.O. dewatering system
  • Delivering Capability – 100 – 400 lbs/min
