Truck 1

The specialized truck is engineered for high performance in wet and dry conditions. The entire system is managed by a proportional CAN electrically controlled hydraulic system. It features substantial storage capacity, including a 3,000-gallon emulsion tank, a 5-ton (5T) AN Prill bin, a 110-gallon fuel oil tank, an 80-gallon gassing tank, and a 240-gallon water tank. Operational efficiency is maximized by several advanced components, notably a 160-gallon final product hopper with a continuous level probe, a 20ft long overhead auger, and integrated pneumatic bin vibrators to loosen any clumped product.

For system protection and safety, the truck includes a heat exchanger to regulate hydraulic oil temperature, a hydraulic gate valve to isolate the auger from the Prill bin, and a four-sided, hydraulically controlled guard rail. The hose reel features a 2-axis control that allows for independent extension and retraction of both the boom and drum, culminating in a robust delivery capability of 200-700 lbs/min pump rate and an auger rate of 200-1,000 lbs/min.

Features Include:

  • 3,000 Gallon Emulsion Tank
  • 5T AN Prill bin
  • 60-gallon gassing tank
  • 110-gallon fuel oil tank
  • Gate Valve
  • Bin Vibrators
  • 160-gal final product hopper
  • Pump Delivering Capability – 200 – 700 lbs/min
  • Auger Delivering Capability – 200 – 1,000 lbs/min
